Van Wijk Launch 1030 (Fast) Sold
Dimensions (m):
10.30 x 3.60 x 0.95
Ref. no.:
100308
Mooring:
Near 's-Hertogenbosch, Netherlands
Construction year:
2004
Material:
GRP
Vision Doeve Brokers
Speedy boat built by the best fast going launch builder in the Netherlands. She is well maintained. Highly recommended and suitable to sail this season. large foredeck, small cabin structure, beamy sidewalks, windscreen, super cockpit (selfdraining), canoe stern with hanging rudder, construction number 6.
More information
General information
| Yard: | Yard Van Wijk NL-Woubrugge |
| Designer / Architect: | Pieter Beeldsnijder Yacht Architect |
| Hull shape: | deep-V |
| Hull material: | GRP |
| Deck material: | GRP sandwich teak deck(s) |
| Superstructure material: | GRP sandwich |
| Construction method: | open cockpit half plane hull self-draining cockpit canoe stern teak in cockpit teak on cockpit bench stainless steel cleats |
| Steering system: | manual hydraulic steering wheel emergency tiller GRP rudder attached rudder |
| Windows: | aluminium windows frames aluminium windshield |
| Displacement (approx.): | 4500 kg |
| Airdraft (approx.): | 1,85 m everything down |
| Owner: | Dutch owner |
| Colour / Paint System: | blue hull white superstructure well maintained |
| RCD / CE Certification: | C 12-pers. |
| Suitable for / as: | recreational vessel coastal waters inland waterways |
| General information: | good sailing characteristics |
| Additional information: | rope fender around bow fender halfglider classic lines motor cruiser roomy foredeck |
Technical information
| Enginepower: | 315 Hp 232 kW |
| Engine brand: | Yanmar |
| Revolutions: | 3800 RPM |
| Engine model: | inboard engine 6 LPA-STR, 24 Valve |
| Number of cylinders: | 6 |
| Construction year engine: | 2004 into operation |
| Running hours (approx.): | 350 on the hour counter |
| Fuel: | diesel |
| Fuel tank (approx.): | 520 litre 2 stainless steel tank(s) |
| Cooling system: | intercooling wet exhaust |
| Propulsion: | propeller shaft water lubricated propeller shaft |
| Gearbox: | hydraulic ZF Hurth |
| Trim tabs: | electric/hydraulic |
| Speed (approx.): | 25 knots top speed |
| Heating: | Webasto Airtop 3500 hot air heating on diesel |
| Engine instruments: | yes |
| Bow thruster: | 55 KGF Vetus 12 Volt electric bow thruster 12 Volt |
| Electricity system: | 12 Volt 230 Volt 230 Volt shore power connection Mastervolt mainmaster control |
| Batteries: | 1x 125 Amp/hours 2x 120 Amp/hours 1x 125 Amp/hours maintenance free |
| Battery charger: | combi inverter/charger |
| Battery isolator: | battery isolator |
| Earth-leakage breaker: | earth leakage circuit breaker |
| Inverter: | Mastervolt Dakar combi inverter/charger 12/1500/65 |
| Fresh water tank (approx.): | 188 litre 1 stainless steel tank(s) |
| Water pressure system: | electric water pump |
| Hot water system: | 22 ltr. boiler/water calorifier via 230 Volt and engine cooling system |
| Holding tank (approx.): | 60 litre |
| Diesel waterseparator: | Yanmar diesel waterseparator |
| Engineroom: | ventilated |
| Bilge pump: | electric pump manual pump |
| Deck wash pump: | electric pump |
| Gas system: | no gas on board |
Accommodation
| Interior: | teak interior professionally done very well maintained see photographs |
| Insulation: | sandwich construction good sound insulation |
| Berth: | Forward: 1x 2-pers. Dinette: 1x 2-pers. 2x electrically adjustable aluminum legs |
| Upholstery: | Viva-Vinyl, see photographs |
| Bathroom: | washbasin Corian mixer tap with hot & cold running water hand shower teak grating in 1 area together with the toilet |
| Toilet / Heads: | pumptoilet |
| Cooker: | 2-burner hob Wallas diesel/ceramic |
| Fridge / Refrigerator: | 12 Volt fridge / refrigerator Frigoboat 1x coolbox |
| Freezer: | small ice compartment |
| Worktop: | Corean worktop |
| Washbasin: | stainless steel sink |
| Water tap: | mixer tap with hot & cold running water |
| Headroom (approx.): | saloon (approx.) 1,92 m toilet (approx.) 1,80 m |
| Additional information: | very well maintained |
Navigation equipment
| Navigation equipment: | compass Raymarine ST40 bi-data depth / echosounder Raymarine ST40 bi-data log / speed Raymarine RC435 chartplotter / GPS 2x window wiper horn navigation lights |
Equipment
| Anchor equipment: | electric anchor winch warping drum Pool anchor Stainless steel 25 m anchor chain 25 m anchor line specified length(s) is/are approximate |
| Outdoor cushions: | cockpit cushion(s) |
| Sprayhood: | sprayhood |
| Cabriocap: | cabriocap stainless steel frame |
| Safety: | automatic fire extinguishing system in engine room fire extinguisher |
| Additional information: | deck lights teak cockpit table fenders |
